a (left). Design for chimney at Johnson's Iron Works, Ferry Street.

Figure 87a:

Design for chimney at Johnson's Iron Works c1845.

(left). Design for chimney at Johnson's Iron Works, Ferry Street.

Roumieu & Gough, architects, c1845 (p. 516). Demolished

b. Chimney at Cumberland Oil Mills, built 1857, in 1987 (p. 523).

Figure 87b:

Chimney at Cumberland Oil Mills in 1987.

Chimney at Cumberland Oil Mills, built 1857, in 1987 (p. 523).

Demolished

c. Westwood, Baillie & Company's London Yard, Cubitt Town, in the early 1860s (pp. 533, 535)

Figure 87c:

Westwood, Baillie & Company's London Yard in the early 1860s.

Westwood, Baillie & Company's London Yard, Cubitt Town, in the early 1860s (pp. 533, 535)
